DIN960 Hexagon Bolt Half Thread (Fine Thread)
Material:
CL 8.8
Finishing
CL 8.8 comes in Black Oxide and Zinc Plated finishing
Note:
Drop us an email if you have other coating requirement
Read More:
Product Description
| Size | M8 | M10 | M10 | M10 | M12 | M12 |
| Pitch | 1.0 | 1.0 | 1.25 | 1.25 | 1.25 | 1.5 |
| Width Across Flats (A/F) | 13MM | 17MM | 14MM | 17MM | 19MM | 19MM |
| Width Across Corners (max.) | 14.38MM | 18.9MM | 15.6MM | 18.9MM | 21.1MM | 21.1MM |
| Head Height | 5.3MM | 6.4MM | 6.4MM | 6.4MM | 7.5MM | 7.5MM |
| Length | 35MM – 70MM | 40MM – 60MM | 40MM – 150MM | 40MM – 110MM | 45MM – 150MM | 45MM – 150MM |
| Size | M14 | M16 | M18 | M20 | M22 | M24 |
| Pitch | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
| Width Across Flats (A/F) | 22MM | 24MM | 27MM | 30MM | 32MM | 36MM |
| Width Across Corners (max.) | 24.49MM | 26.75MM | 30.14MM | 33.53MM | 35.72MM | 39.98MM |
| Head Height | 8.8MM | 10MM | 11.5MM | 12.5MM | 14MM | 15MM |
| Length | 50MM – 150MM | 55MM – 150MM | 60MM – 160MM | 65MM – 180MM | 70MM – 150MM | 75MM – 150MM |
