Button Head Cap Screw (UNC)
Material :
Steel , Stainless Steel 304 (A2)
Finishing :
Steel comes in Black Oxide and Zinc Plated Finishing
Note:
Drop us an email if you have other coating requirement
Read More:
Product Description
| Diameter Size | #2-56 | #4-40 | #5-40 | #6-32 | #8-32 | #10-24 |
| A/F | 1.27MM | 1.5MM | 2MM | 5/64 | 3/32 | 1/8 |
| Length | 1/8 – 1″ | 3/16 – 1″ | 1/4 – 3/4 | 3/16 – 1-1/2 | 3/16 – 2″ | 1/4 – 2″ |
| Head Diameter (max) | 4.2MM | 5.4MM | 6.0MM | 6.7MM | 7.9MM | 9.2MM |
| Head Height (max) | 1.2MM | 1.5MM | 1.7MM | 1.9MM | 2.2MM | 2.6MM |
| Diameter Size | 1/4 | 5/16 | 3/8 | 1/2 |
| T.P.I | 20G | 18G | 16G | 13G |
| A/F | 5/32 | 3/16 | 7/32 | 5/16 |
| Length | 3/8 – 3″ | 1/2 – 3″ | 5/8 – 5″ | 3/4 – 6″ |
| Head Diameter (max) | 11.1 | 13.9 | 16.7 | 22.2 |
| Head Height (max) | 3.4 | 4.2 | 5.1 | 6.7 |
